How to Use the Kanban Board for Multi-Agent Workflows in Hermes Agent

TLDR: Hermes Agent has a built-in kanban board for multi-agent coordination. Initialize it with hermes kanban init, create tasks with hermes kanban create "Task title", assign them to profiles with hermes kanban assign TASK_ID profile-name, and let workers claim and complete them via their restricted toolset. For hands-off operation, enable the automatic dispatcher in config.yaml.

Key Takeaways

• The kanban board is a durable SQLite store — tasks survive agent restarts
• Worker agents see only their assigned tasks through a restricted toolset
• Automatic dispatching reclaims stale claims and promotes ready tasks
• Board isolation keeps work across projects separate
• Use tenants within a board for workspace-path + memory-key isolation

What Is the Kanban Board?

The kanban board is a durable multi-agent work queue built into Hermes Agent. It lives in a SQLite database and coordinates work across profiles (independent Hermes instances).

Think of it as a project board where:

• You create the tasks and assign priorities
• The dispatcher routes work to the right agent
• Worker agents pick up tasks, heartbeat progress, and mark them complete
• The board tracks everything — status, assignments, comments, and links

Unlike delegate_task (which runs subagents synchronously within a session), the kanban board is persistent and asynchronous — agents come and go, but the board holds the state.

Step 1: Initialize a Board

Every kanban workflow starts with a board:

hermes kanban init

This creates a SQLite database at ~/.hermes/kanban/ with a default board. You can have multiple boards for different projects:

hermes kanban init --name "client-work"
hermes kanban init --name "open-source"

Each board is fully isolated — tasks, assignments, and comments never leak between them.

Verify it worked:

hermes kanban list

Expected output (empty board):

No tasks found. Create one with `hermes kanban create "Task title"`

Step 2: Create and Manage Tasks

With a board initialized, start populating it with work items:

# Create a task
hermes kanban create "Refactor authentication module"

# Create with priority
hermes kanban create "Fix production database timeout" --priority high

# Create with a description
hermes kanban create "Update CI/CD pipeline" --description "Migrate from GitHub Actions to self-hosted runners"

Each task gets a numeric ID. Use that ID for all subsequent operations:

# List all tasks with their IDs and status
hermes kanban list

# Show full details of a specific task
hermes kanban show 1

# Add a comment
hermes kanban comment 1 "Started investigation — discovered the issue is a missing index"

# Add a comment with status hint
hermes kanban comment 1 "Blocked — waiting for DevOps to provision new instance" --status blocked

The list output shows each task with its ID, title, status (pending, active, completed, blocked, archived), assignee, and priority.

Task Lifecycle

pending → active → completed
             ↓
          blocked
             ↓
          unblocked → active

The board tracks the full lifecycle. Blocked tasks stay in place until unblocked — nothing is lost.

Step 3: Assign Work to Agents

Tasks sit on the board until someone claims them. You can assign explicitly:

hermes kanban assign 1 "backend-agent"
hermes kanban assign 2 "frontend-agent"

The assignee value is a profile name — the same ones you see in hermes profile list. This connects the kanban system to your multi-profile setup.

Worker agents interact with the board through a restricted toolset. When a worker starts with HERMES_KANBAN_BOARD set in its environment, it gets only these tools:

Tool	Purpose
kanban_show	View task details and comments
kanban_complete	Mark a task as done
kanban_block	Report a blocker
kanban_heartbeat	Signal the agent is still working
kanban_comment	Leave a note on the task
kanban_create	Split work into sub-tasks
kanban_link	Connect related tasks

Workers cannot see the full board or reassign tasks — they only see what’s assigned to them.

Step 4: Enable Automatic Dispatching

Manual assignment works for small teams. For production-scale workflows, enable the automatic dispatcher. This runs inside the Hermes gateway and handles:

• Claiming — atomically assigns a pending task to an available agent
• Heartbeat monitoring — reclaims tasks from workers that stopped responding
• Promotion — moves tasks from pending to ready when dependencies are met
• Failure handling — auto-blocks a task after ~5 consecutive spawn failures

Configuration

Add this to ~/.hermes/config.yaml:

kanban:
  dispatch_in_gateway: true
  heartbeat_timeout: 300
  max_retries: 5
  board_path: "~/.hermes/kanban/default.db"

Field	Default	Purpose
dispatch_in_gateway	true	Run the dispatcher loop inside the gateway process
heartbeat_timeout	300	Seconds after which a stale claim is reclaimed
max_retries	5	Consecutive spawn failures before auto-blocking
board_path	~/.hermes/kanban/default.db	Which board the dispatcher manages

Apply with:

hermes config set kanban.dispatch_in_gateway true

Then restart the gateway for changes to take effect:

hermes gateway restart

With dispatching active, the workflow becomes fully automatic:

1. You create a task
2. The dispatcher picks it up and spawns the assigned profile
3. The worker claims the task, does the work, and marks it complete
4. The dispatcher reclaims the worker for the next task

Board Isolation for Multi-Tenant Setups

For teams or multi-project environments, use the tenant feature:

kanban:
  tenants:
    acme-project:
      board: client-work
      workspace: ~/projects/acme
    internal-tools:
      board: default
      workspace: ~/projects/internal

Tenants provide soft namespace isolation within a board — each tenant gets its own workspace path and memory key prefix, preventing context leakage between unrelated work streams.

Step 5: Worker Agents Claim and Complete Tasks

When you spawn a worker agent with the kanban toolset, it automatically sees its assigned tasks:

# Start a worker agent (from within the board's context)
hermes --profile "backend-agent" -s "kanban-worker"

Inside the session, the worker’s agent can use the kanban toolset. These are agent-level tools, not shell commands — the agent calls them programmatically as it works through the task:

• kanban_show — displays the current task’s details, including description, priority, and any comments left by the board owner or other workers
• kanban_heartbeat — sends a progress signal to the dispatcher, resetting the claim timeout
• kanban_complete — marks the task as done and signals readiness for the next assignment
• kanban_block — sets the task status to blocked with an explanation
• kanban_comment — appends a note to the task (useful for handoffs between workers)
• kanban_create — spawns sub-tasks when the agent finds the work needs decomposition
• kanban_link — connects this task to related tasks on the board

You’ll see these in action in the agent’s tool call output during a session. For example, when a worker agent finishes a task, it automatically calls kanban_complete, and the board updates immediately.

The kanban_heartbeat tool is critical for long-running tasks — it tells the dispatcher the agent is still alive. Without heartbeats, the dispatcher reclaims the task after heartbeat_timeout seconds.

End-to-End Workflow

Here’s the complete cycle for a two-agent kanban setup:

Terminal 1 — Board setup:

hermes kanban init
hermes kanban create "Build REST API for user management" --priority high
hermes kanban create "Build React dashboard" --priority medium
hermes kanban assign 1 "backend-agent"
hermes kanban assign 2 "frontend-agent"

Terminal 2 — Backend worker:

hermes --profile "backend-agent" -s "kanban-worker" --worktree

The worker sees task 1, builds the API, and calls kanban_complete.

Terminal 3 — Frontend worker:

hermes --profile "frontend-agent" -s "kanban-worker" --worktree

The worker sees task 2, builds the dashboard, and calls kanban_complete.

Back in Terminal 1 — Verify:

hermes kanban list

Both tasks should show as completed. Use hermes kanban show 1 for full details including comments left by each worker.

Advanced Features

Linking Related Tasks

When tasks depend on each other, link them:

hermes kanban link 1 2
hermes kanban link 1 3

The dispatcher won’t promote linked tasks to ready until their dependencies are complete.

Archiving Completed Work

Keep the board clean without losing history:

hermes kanban archive 1
hermes kanban archive --completed

Archived tasks are hidden from kanban list but preserved in the database. Restore with hermes kanban unarchive.

Monitoring with kanban tail

Watch board activity in real time:

hermes kanban tail

Shows task creations, assignments, claims, completions, and blocks as they happen — useful for debugging dispatching issues.

Statistics

Get a high-level overview:

hermes kanban stats

Shows counts per status, average time-to-complete, and dispatcher run history.

Verification Checklist

Run through this to confirm your board is working correctly:

# 1. Board exists and is accessible
hermes kanban list

# 2. Task creation works
hermes kanban create "Test task" && hermes kanban list | grep "Test task"

# 3. Assignment works
hermes kanban assign "$TASK_ID" "worker-profile" && hermes kanban show "$TASK_ID" | grep -i "assign"

# 4. Worker toolset is restricted (start a worker, check available tools)
hermes --profile "worker-profile" -s "kanban-worker" -q "List the tools I have available"

# 5. Completion works
hermes kanban complete "$TASK_ID" && hermes kanban show "$TASK_ID" | grep -i "complete"

# 6. Dispatcher status (if enabled)
hermes kanban log | tail -5

Common Issues

”No tasks found” but I created some

Check you’re using the correct board. If you initialized with --name, you must reference it:

hermes kanban list --board "client-work"

Worker doesn’t see kanban tools

The kanban worker toolset is gated by the HERMES_KANBAN_BOARD environment variable. Worker profiles launched via hermes kanban dispatch get this automatically. For manual spawning, set it in the profile’s config:

hermes --profile worker config set env.HERMES_KANBAN_BOARD "default"

Dispatcher not picking up tasks

Check the dispatcher log:

hermes kanban log

Common causes:

• dispatch_in_gateway is false — no dispatcher running
• Heartbeat timeout too short for long tasks — increase heartbeat_timeout
• Worker profile fails to spawn 5+ times — task auto-blocks; unblock with hermes kanban unblock TASK_ID

Next Steps

Now that your kanban board is operational, try these advanced patterns:

• Cron-fed boards — use hermes cron create to generate tasks on a schedule, then let the dispatcher route them
• Multi-tenant boards — isolate client projects with the tenant system
• Linked pipelines — chain task A → B → C with kanban link for multi-stage workflows
• Webhook integration — use hermes webhook subscribe to add external triggers that create board tasks
